4.7.5 Resetting values of the status reporting system
Table 4-12 comprises the different commands and events causing the status reporting system to be
reset. None of the commands, except for *RST, influences the functional device settings. In particular,
DCL does not change the device settings.
Table 4-12 Resetting device functions
Event
Switching on supply
voltage DCL, SDC
(Device Clear,
Selected Device
Clear)
*RST STATus:PRESet *CLS
Effect
Clear STB, ESR yes    yes
Clear SRE, ESE yes    
Clear PPE yes    
Clear EVENTt sections of
the registers
yes    yes
Clear ENABle section of all
OPERation and
QUEStionable registers,
Fill ENABle sections of all
other registers with "1".
yes   yes 
Fill PTRansition sections
with "1" ,
Clear NTRansition sections
yes   yes 
Clear error queue yes    yes
Clear output buffer yes yes 1) 1) 1)
Clear command processing
and input buffer
yes yes   yes
1) The first command in a line, ie immediately following a <PROGRAM MESSAGE TERMINATOR>
clears the output buffer.
