Operating Instructions D50+ | P50+ | SHERAprint 50
Rapid Shape GmbH
│
DOCR000438
36
│
96
7.2
Menu Overview
7.3
Verifying the Mac
hine Status
The machine is equipp
ed with a stat
us LED that indicates t
he various
machine statuses. The in
dividual signal colours a
nd s
ignal types are
described below:
Colour
Signal Type
Descripti
on
permanent
Idle state, machine is r
eady for op
eration.
permanent
Machine is printing.
flashing
User action required (e.g. k
nife protectio
n
device opened, polymer
ised residue
detected in reservoir,
etc.).
permanent
Fault is present.
35
37
