1.3.3 References
References to other sections in the document are shown with paragraph number, header text and/or
page number:
• Example: Please also note 2 Layout and function
References to other documents are shown as information or instructions without the exact chapter or
page number:
• Example: Follow the instructions in the operator’s manual of the universal drive shaft
manufacturer.
1.3.4 Menu hierarchy, keys and navigation
Menus are the entries listed in the main menu window.
The menus list submenus and/or menu items where settings can be made (selection lists, text or
number entries, starting a function).
The various menus and buttons of the machine control unit are illustrated in bold letters.
The hierarchy and the path to the requested menu item are marked with an > (arrow) between menu
and/or menu item(s):
• System / Test> System / Test > Test/diagnosis means that you can reach the menu item Voltage
via the menu item System / Test and the menu item Test/diagnosis.
○ The arrow > corresponds to the operation of the scroll wheel and/or the button at the screen
(touchscreen).
1. User instructions
AXIS EMC ISOBUS 5902180-h-gb-
