Chapter 1: System Integration -13
1.3 How is the C-Series display integrated?
This section details the recommended methods of integration.
SeaTalk system
In this system:
• C-Series powers SeaTalk for an alpha numeric keypad and RS 120.
• The DSM has a dedicated cable supplied with the unit and does not require a
terminator at the C-Series end.
RANGE
CANCELOK
PAGE
ACTIVE
WPTS/
MOB
MENU
DATA
IN
OUT
DSM 250
Power
IN
Power
IN
Alpha-numeric
keypad
Radome
GPS
C-Series Display
Terminator
DSM
Radar
SeaTalk SeaTalk
D6610-1
Power
IN
