Integrated system1
In this system:
• PC displays instrument information and shares routes and waypoints.
• SeaTalk is powered independently.
• SeaTalk bus must remain powered when C-Series is off so that the radio
continues to receive GPS data.
• Open arrays must be powered using the split cable.
RANGE
CANCELOK
PAGE
ACTIVE
WPTS/
MOB
MENU
DATA
IN
OUT
MENU
CH
OK
16/9
HI/LO
SCAN WATCH
SQ
RAY240
WX
Power
IN
Power
IN
D6622-1
Wind Transducer
Open Array
Wind
display
Speed
display
Depth
display
DSM 250
C120
Depth
Transducer
Speed
Transducer
Transducer
Power
IN
Power
IN
Power
IN
GPS
VHF/DSC
Radio
RS232
Interface box
RS232
Interface box
NMEA
NMEA
SeaTalk
NMEA
