-38 C-Series Displays Installation Manual
How do I remove the front bezel?
To remove the front bezel:
1. Using a flat-bladed screwdriver placed in the aperture at the top right of the bezel,
gently twist it to release the top clips.
2. Working from this corner, free the clips along the top edge of the display, then work
towards the bottom edge. Taking care to ensure that the control buttons pass
through the bezel. DO NOT lever along the top edge.
3. Carefully free the locating clips at the bottom of the bezel by lowering it away from
the unit - DO NOT USE A SCREWDRIVER FOR THIS AS IT WILL DAMAGE THE CLIPS.
4. Remove the bezel from the display.
D6616-1
