58 C-Series Displays Installation Manual
Connectors 13 pin Radar scanner
4 pin DSM
3 pin SeaTalk
5 pin NMEA
5 pin SeaTalk
2
/ NMEA2000
3 pin Power
Interfaces Pathfinder Radar scanner
1 x DSM receive
1 x SeaTalk, receive and transmit
1 x NMEA0183, receive and transmit
1 x SeaTalk
2
/ NMEA2000
CompactFlash card slot
Waypoints 1000 waypoints entered via cursor, lat/lon, range and bearing from
present position or at boats position.
16 character name can be assigned.
Waypoint symbols and groups
Additional storage available on CompactFlash cards
Waypoint Transfer Waypoints database via NMEA
Man Overboard (MOB Mode) Mark placed with course line; readout shows range, bearing, lat/
lon of MOB and time elapsed since MOB
Screen functions Full, half and quarter screens available dependant on function. Also
3 window page with 2 x 1/4 page windows and 1 x 1/2 page
window
Information Displayed in horizontal or vertical data bar and includes boat data,
navigation data, depth, environmental data and Wind data
Radar/Chart overlay Radar image can be overlaid on all screen charts
Radar Features
Range Scales (Range Rings) 1/8 (1/16)nm to 72 (12) nm dependant on scanner
Performance limited by scanner type and position.
Range Ring Accuracy Better than +/- 1.5% of the max. range scale in use, or 22m (72 ft.),
whichever is the greatest.
Bearing accuracy +/- 1°
Variable Range Markers 2 x VRM’s, readout nm, sm, km
Electronic Bearing Lines 2 x EBL’s, floating if required, resolution 1°
Bearing scale 360° graduated at 10° intervals
2° small ticks
10° large ticks
Minimum range 23m (25 yds)
Range Discrimination 23m (25 yds)
Presentation Modes Head up, Course up or North up (selectable True or Magnetic)
Relative or True Motion
