60 C-Series Displays Installation Manual
Navigation information Own boats position in lat/lon, XTE, TTG and SOG/COG selectable.
Bearing and distance to waypoint. Bearing and distance to cursor
and ETA.
Variation Source Auto (SeaTalk/NMEA/Internal algorithm) or Manual
Fishfinder
Transducer Transom-mount, in-hull or thru-hull
Output power:
Standard transducer
High performance transducer
Adjustable to 600 watts RMS
Adjustable to 1000 watts RMS
Frequency Dual 50 kHz and 200 kHz
Pulse length 100 usec to 4 msec
Maximum Transmit Rate 1580 pulses/ min at 50 ft range
Depth:
Standard transducer
High performance transducer
3 ft (1m) to 3000 ft (1000m)
3 ft (1m) to 5000 ft (1700m)
Alarms Fish alarm, fish alarm depth, shallow and deep fish limit
Interfacing
DSM connection for communication with DSM High Definition Fish Imaging (HDFI)
NMEA Input NMEA 0183 GLL, GGA, GLC, GTD, VTG, BWC, BWR, RMA, RMB, RMC, XTE,
VHW, HDG, HDM, HDT, DBT, DPT, APB, VLW, MWV, WPL, RTE and
ZDA
NMEA Output - User selectable APB, BWC, BWR, DBT, DPT, GGA, GLL, MTW, RMA, RMB, RMC, RSD,
TTM, VLW, VHW, VTG, WPL and ZDA
SeaTalk Input Depth,SOG,COG, Position, Waypoint number, range/ bearing, TTG,
Boat speed, Time, XTE, Heading, Wind, data, Log/Trip, Pilot status,
Temperature, MOB and cursor position
SeaTalk Output Cursor data, guard zone and navigational data bridged from NMEA
Chartplotter Features
