-36 C-Series Displays Installation Manual
5. Remove the mounting bracket knobs and the mounting bracket from the display
unit. Make sure the unit fits in the area that has been cut out.
6. Drill four 4.5 mm holes as indicated on the template to accept the securing bolts.
7. Place trim ring into the cut-out, ready for securing the unit.
8. Place the gasket onto the display unit.
9. Connect the DC power cable, scanner cable, SeaTalk and Fishfinder connector
cables to the display, avoiding tight bends.
10. Slide the unit into the console and secure using the trim ring and suitable length
bolts (see table below)
11.Locate the bezel over the front of the display as detailed below.
Fixing bolts
When console mounting your C-Series Display to avoid damaging the rear trim
ring, the following length of bolts should be used dependant upon bulkhead
thickness:
Bulkhead Thickness (mm) Bolt length (mm)
0-3 12
3-7 16
7-11 20
11-15 24
15-19 28
19-23 32
