Appendix A: Specification 101
Appendix A: Specification
This appendix provides the physical and electrical specification for the
chartplotter.
CE conforms to 89/336/EEC(EMC), EN60945:1997
Size 226 mm x 332 mm x 84 mm (8.9 in x 13.1 in x 3.3 in), excluding trunnion
Weight 1.8 kg (64 oz)
Environmental
Waterproofing To CFR46; suitable for external mounting
Temp Range - Operating Mono : 0°Cto 70°C., Colour: 0°C to 50°C
Temp Range - Storage Mono: -20°C to 70°C, Colour: -20°C to 60°C
Humidity 20% to 95% RH
Mounting Trunnion (yoke) or panel
Power Input 12Vdc to 32Vdc nominal
10.7Vdc to 44Vdc Absolute maximum range
Consumption- Typical Mono: 4 W Colour: 10 W
Consumption - Maximum Mono: 9 W Color: 18 W
(Power consumption of an external GPS to be added)
Controls 8 defined keys, 4 soft keys and trackpad
Display type 640 x 480 VGA quality LCD
either: colour with 64 colours
or: monochrome with 4 grey scales
Display size 10.4 in diagonal (211 mm x 158 mm) - colour
9.7 diagonal (196 mm x 148 mm) - monochrome
Interfaces SeaTalk receive and transmit
NMEA 0183 receive and transmit
Printer
Position data GPS, dGPS
Cartography C-MAP NT C-Cards
Software update Via C-Card
Memory Capacity: Waypoints/events: 1000 (20 routes of 50 waypoints)
Marks: 1000
Track histories: 5000 points, 5 files
Protection: Built in Lithium battery giving 3 to 5 years storage
External: C-MAP Memory C-Cards for data storage/retrieval
