iv
RayChart 620 and 630
How to Use this Handbook
This handbook is organized with the information about operating the
chartplotter at the front, since you will probably use these chapters most often.
When you first receive your chartplotter, you should read Chapter 7, and install
the equipment. Then read Chapters 1 and 2 to familiarize yourself with the
controls of the chartplotter. You may also wish to read Chapters 3, 4 and 5.
When you are happy with the basics of using the chartplotter, read Chapter 6,
decide how you wish to set up your defaults, alarms and the screen, and follow
the instructions to make your changes.
Once you are on the water, you can follow the instructions in Chapters 3 and 4
to perform all your routine tasks, and refer to Chapter 5 for information about
more advanced features.
If you experience any difficulties with your chartplotter, refer to Chapter 8.
Refer to the Glossary if there are any terms you are unfamiliar with.
Note: The Quick Reference Card, included with your system, provides a useful
summary of the chartplotter controls.
Text Conventions
Throughout this handbook, the dedicated (labelled) keys are shown in bold
capitals; for example, MENU. The soft (unlabelled) key functions, menus and
options are shown in normal capitals; for example, ROUTE.
Operating procedures, which may consist of a single key-press or a sequence of
numbered steps, are indicated by the ➤ symbol in the margin.
Terms included in the glossary are shown in bold type.
Exercises are shown in italic type, like this paragraph.
Warranty
To register your chartplotter ownership, please take a few minutes to fill out the
warranty registration card found at the end of this handbook. It is very important
that you complete the owner information and return the card to the factory in
order to receive full warranty benefits.
EMC Conformance
All Raytheon equipment and accessories are designed to the best industry
standards for use in the leisure marine environment.
Their design and manufacture conforms to the appropriate Electromagnetic
Compatibility (EMC) standards, but correct installation is required to ensure
that performance is not compromised.
