Servo Connection
Connect the servos to the appropriate positions in the transceiver:
Connect… …into transceiver receptacle
Receiver battery / Channel 4 servo “Power”
Steering servo “Steering”
Throttle servo or ESC “Throttle”
Shifting servo “Shft/CH3”
FCC Compliance Reminder
If you install the React transceiver inside of a vehicle, and you are not the final end user, FCC
regulations require you to make the React Transceiver’s FCC ID easily visible to the end user. See the
FCC Compliance section for more information:
