Top Menu Level

The following illustration shows the function menu structure for the top-level menu. All main sub-

menus may be accessed from the top menu level. Channels 3 & 4 have identical setups, and are

documented together.

Manage Models

Active Model

New Model

Delete Model

Copy Model

Rebind

Main Page
