Throttle Servo Reverse
Throttle servo reversing reverses
the direction the throttle servo
moves upon receiving an input
from the throttle trigger.
Changing the Throttle Servo Reverse Setting
Use the navigation controls to change the throttle servo reverse setting as follows:
1. Access the top function menu from the
driving screen.
2. Navigate to the Throttle (Ch2) menu.
or then
3. Navigate to Servo Reverse.
or
Value Description
Off Standard servo direction.
4. Change the value.
or
On Reversed servo direction.
