RED DSMC OPERATION GUIDE
COPYRIGHT © 2014 RED.COM, INC 955-0020_V5.2, REV-G | 79
FORMAT
Use the Format menu to select the resolution, aspect ratio, anamorphic setting, and lookaround setting.
After selecting format settings, select Set Format.
EPIC DRAGON FORMATS
The table below describes the formats that are available for EPIC DRAGON.
Default for EPIC DRAGON is 6K 2:1.
The table below omits rows for the anamorphic formats, since the pixel dimensions for each anamorphic format
and the corresponding non-anamorphic format are the same. For more information, go to “Anamorphic” on
page 84.
EPIC DRAGON offers a 6:5 aspect ratio for each resolution. Using a 6:5 aspect ratio at 2x anamorphic gives
you a 2:40:1 aspect ratio.
RESOLUTION DESCRIPTION DIMENSIONS (PIXELS)
WIDTH HEIGHT
6K FF 6K RAW Full Frame 6144 3160
6K 2:1 6K RAW 2:1 6144 3072
6K WS 6K RAW Wide Screen—2.4:1 6144 2592
6K HD 6K RAW HD—16:9 5568 3132
6K 6:5 6K RAW 6:5 3792 3160
6K 4:1 6K RAW 4:1 6144 1536
6K 8:1 6K RAW 8:1 6144 768
5.5K FF 5.5K RAW 5632 2948
5.5K 2:1 5.5K RAW 2:1 5632 2816
5.5K WS 5.5K RAW Wide Screen—2.4:1 5632 2376
5.5K HD 5.5K RAW HD—16:9 5376 3024
5.5K 4:1 5.5K RAW 4:1 5632 1408
5.5K 8:1 5.5K RAW 8:1 5632 704
5K FF 5K RAW Full Frame 5120 2700
5K 2:1 5K RAW 2:1 5120 2560
5K WS 5K RAW Wide Screen—2.4:1 5120 2160
5K HD 5K RAW HD—16:9 4800 2700
5K 6:5 5K RAW 6:5 3240 2700
5K 4:1 5K RAW 4:1 5120 1280
5K 8:1 5K RAW 8:1 5120 640
4.5K FF 4.5K RAW 4608 2412
4.5K 2:1 4.5K RAW 2:1 4608 2304
4.5K WS 4.5K RAW Wide Screen—2.4:1 4608 1944
4.5K HD 4.5K RAW HD—16:9 4224 2376
4.5K 3:2 4.5K RAW 3:2 4320 2880
