15
◈ Description on Menu
If press the button, entering to the menu mode. It is same function of operation keys. Press and hold the
button for more than 3 seconds to enter each menu.
Exchange the tools.
Check XY coordinate.
※If the machine is restarted, set value is reset.
Check Z coordinate.
※If the machine is restarted, set value is reset.
Check A coordinate.
※If the machine is restarted, set value is reset.
Select the measurement
option the material’s height.
Surface Height/ Horizontal, Shape
Verticality, Shape/ Surface Slope
When repetitive work, Select
the measurement option of
material height and engraving
area.
1. Skip the all measurements.
2. Measure the height.
3. Check the all measurements.
Select how to check the
engraving area before starting
to engrave ring inner diameter.
Spindle test is running.
