Replacement and
Adjustment
D454 22
SM
2.
Positioning roller motor bracket [A] (
x
1,
x
1,
x
2)
3.
Positioning roller motor [A] (
x
2)
1.3.9 1ST
STOPPER
MOTOR
1.
1st stopper unit (
p.19)
