Ricoh Aficio MP 7001 SP Service Manual

Input/Output Check
SM Appendix 4-265 D062/D063/D065/D066
Appendix:
Service
Program
Mode Tables
4.2.8 FINISHER 2 OUTPUT CHECK: SP6124
6125 Finisher Output Check: Finisher 2 (Finisher D460)
001 Main Motor
002 Shift Tray Exit Motor
003 Proof Junction Gate SOL
004 Shift Relay Motor
005 Jogger Motor
006 Stapler Moving Motor
007 Stapler Motor
008 Punch Motor
009 Stapler Solenoid
010 Knock Roller Motor
Turn on the electrical components of
the finisher individually for test
purposes. See " Finisher 2 Output
Check: SP6125"
011 Stack Feed-out Motor
012 Shift Motor
013 Staple Lift Motor
014 Staple Exit Motor
015 Exit Motor
016 Hold Motor
017 Pre-stack Solenoid
018 Guide Solenoid
019 Stapler Release Solenoid
020 Front Hold Motor
Turn on the electrical components of
the finisher individually for test
purposes. See "Finisher 2 Output
Check: SP6125"
021 Rear Hold Motor Turn on the electrical components of
