Input/Output Check
D062/D063/D065/D066 4-266 SM Appendix
022 Reverse Drive Motor
023 Reverse Feed Motor
024 Exit Jogger Motor
025 Exit Jogger Release Motor
026 Jogger Top Fence Motor
027 Jogger Bottom Fence Motor
the finisher individually for test
purposes. See " Finisher 2 Output
Check: SP6125"
4.2.9 FINISHER 3 INPUT CHECK: SP6309
6309 Fold Unit (D454) Input Check
001 Entrance Sensor
002 Entrance JG HP Sensor
004 Registration Sensor
005 Dynamic Roller HP Sensor
006 Registration Roller HP Sensor
007 Fold Plate HP Sensor
008 Jogger Fence HP Sensorr
009 Positioning Roller HP Sensor
010 1st Stopper Paper Sensor
011 1st Stopper HP Sensor
012 2nd Stopper Paper Sensor
013 2nd Stopper HP Sensor
014 3rd Stopper Paper Sensor
015 3rd Stopper HP Sensor
Turn on the electrical components
of the finisher individually for test
purposes.
