2. Enter "http://(printer's IP address or host name)/" in your Web browser's URL bar.
Top Page of Web Image Monitor appears.
If the printer's host name has been registered on the DNS or WINS server, you can enter it.
When setting SSL, a protocol for encrypted communication, under environment which server
authentication is issued, enter "https://(printer's IP address or host name)/".
Every Web Image Monitor page is divided into the following areas:
1. Menu area
If you select menu, its content will be shown on the work area, or the sub area.
2. Tab area
Details about each menu appear.
3. Header area
The dialog box for switching to the user mode and administrator mode appears, and each mode's menu will be
displayed.
The link to help and dialog box for keyword search appears.
4. Help
Use Help to view or download Help file contents.
5. Display area
Displays the contents of the item selected in the menu area.
Printer information in the display area is not automatically updated. Click [Refresh] at the upper right in the display
area to update the printer information. Click the Web browser's [Refresh] button to refresh the entire browser
screen.
When User Authentication is Set
For details about logging in to and out of Web Image Monitor, see "If User Authentication is Specified".
Using Web Image Monitor
153
