NOTE1 The shock wave from clamping might make a thin white line 60 mm
from the leading edge. This line is visible when the image is made
by photo mode. By turning on DPS 101-7, the reverse roller
solenoid ON timing is delayed to absorb the shock wave. However,
the above measure sometimes disturbs master registration (image
position on the master).
NOTE2 If the customer does not dispose of the ejected masters even
though full master is indicated (Turning off the main switch resets
full master condition), master eject jams or master eject belt might
slip off. Double master compression prevents the customer from
making a master when the master box is full. However, if this
switch is turned on, the master compression is performed twice for
every master made. This hastens parts wear and may cause
trouble.
NOTE3 The following skip number can be selected by setting DIP SW
103-5 and 103-6.
DPS103
1 Sheet/
1 Rotation
1 Sheet/
3 Rotation
1 Sheet/
5 Rotation
1 Sheet/
8 Rotation
5OFFONOFFON
6OFFOFFONON
If both DPS 103-4 (Mode Clear) and DPS 103-4/5 (Skip Paper
Feed Setting) are selected, Mode Clear mode is selected. (Skip
Feed is ignored.)
2.2 DIP SW TABLE (Image Processing Board)
No. DIP SW Function Remarks
1 DPS 400-1 Test Pattern
Turn off to access test pattern mode
(Normal: ON)
2 DPS 400-1 Dither Pattern
Used to change dither matrix
(ON: 4 x 4, OFF: 6 x 6)
2.3 LED TABLE
No. LED Function Remarks
1 LED 101 Main Motor ON When the main motor turns on, LED lights
2 LED 102
1st Paper Exit
SN Detection
When paper is detected, LED lights
3 LED 103
2nd Paper Exit
SN Detection
When paper is detected, LED light
4 LED 104 Ink Detection
When ink is detected, LED lights
NOTE:
When the drum release lever is raised,
the drum connector is disconnected
and LED turns off.
