Ricoh C211 - Input Mode

3.3 INPUT MODE:
COUNTER
INDICATION
INPUT
0001-1
0002-1
0003-1
0004-1
0005-1
0006-1
0007-1
0008-1
0009-1
0010-1
0011-1
0012-1
0013-1
0014-1
0015-1
0016-1
0017-1
0018-1
0019-1
0020-1
0021-1
0022-1
0023-1
0024-1
0025-1
0026-1
0027-1
0028-1
0029-1
0030-1
0031-1
0032-1
0033-1
SW: Master Eject Detection (Indicator lights when sensor ON)
SW: Pressure Plate Position (Indicator lights when switch ON)
SN: 2nd Original Detection (Indicator lights when sensor ON)
SN: Original Registration Detection (Indicator lights when sensor ON)
SN: 1st Drum Position Detection (Indicator lights when sensor ON)
SN: 2nd Drum Position Detection (Indicator lights when sensor ON)
SN: Master Detection (Indicator lights when master is set)
SN: Master Buckle Detection (Indicator lights when master appears)
SW: Left Cutter (Indicator lights when switch ON)
SW: Right Cutter (Indicator lights when switch ON)
SW: Master Eject Box (Indicator lights when switch ON)
SW: Full Master Detection (Indicator lights when switch ON)
SN: Paper End (Indicator lights when paper is set)
SN: Paper Table Low Limit (Indicator lights when sensor ON)
SN: Paper Table Height (Indicator lights when sensor ON)
SN: Pressure (Indicator lights when sensor ON)
SN: 1st Paper Exit (LED103) (Indicator lights when paper is present)
SN: 2nd Paper Exit (LED102) (Indicator lights when paper is present)
SW: Cover Safety/Drum Detection (Indicator lights when switch ON)
SN: Color Drum (Indicator lights when color
drum is set)
DIP SW-1 (DIP101-1) (Indicator lights when switch ON)
DIP SW-2 (DIP101-2) (Indicator lights when switch ON)
DIP SW-3 (DIP101-3) (Indicator lights when switch ON)
DIP SW-4 (DIP101-4) (Indicator lights when switch ON)
Not Used
SN: Ink Detection (Indicator lights when ink appears)
SN: Thermistor (Indicator lights when temp. is
standard)
Key: Proof (Indicator lights when key ON)
Key: Image Shift + (Indicator lights when key ON)
Key: Image Shift – (Indicator lights when key ON)
SW: Drum Rotation (Indicator lights when switch ON)
SW: Master Manual Cut (Indicator lights when switch ON)
SN: 1st Original Detection (Indicator lights when sensor ON)
Service
Tables
C216 4-7 SM
