2. DIFFERENCE BETWEEN VT2000 SERIES
AND VT2105
No. Iter Remarks
1. CCD
The pixel density of the VT2105 is 300
dots/inch. Corresponding to this, the CCD used
on the VT2105 is the same as the one used on
the SS800 series.
2. Thermal Head
Due to pixel density change, the thermal head
has been changed.
3.
Drum Ink Roller
Layout
To ensure paper separation from the drum, the
ink roller has been shifted forward the paper
feed table.
The distance L has been changed from 5.0 mm
to 3.5 mm.
NOTE:
The optional color drum for the VT2105
is commonly used for the VT2100 series.
(The distance L of the color drum is
4.5 mm)
Number of effective
Pixels:
3648pixels
Reading Length: 309 mm
Photo Signal Storage: 5 ms
Density of thermal
heating elements
300 dots/inch
Number of thermal
heating elements
3072 dots
Memory length 256 mm
VT2100 series VT2105
[A]
[B]
L
[B]
[A]
L’
L = 5.0 mm L’ = 3.5 mm
SM 1-4 C216
