4.3 OUTPUT CHECK MODE
Counter
Indication
Output
1-0
2-0
3-0
4-0
5-0
6-0
7-0
8-0
9-0
10-0
11-0
12-0
13-0
14-0
15-0
16-0
17-0
18-0
19-0
20-0
21-0
22-0
23-0
24-0
25-0
26-0
27-0
28-0
29-0
30-0
31-0
32-0
33-0
34-0
35-0
36-0
37-0
38-0
39-0
ADF Motor Rotates.
ADF Original Pressure Solenoid is energized.
Master Eject Motor rotates.
Pressure Plate Motor rotates.
Reverse Roller Clutch is energized.
Vacuum Fan Motor rotates.
Air Knife Motor rotates.
Increments the Key Counter.
Increments the Master Counter
Increments the Total Counter.
Ink Supply Solenoid is energized.
Drum Lock Solenoid is energized.
Printing Pressure Solenoid is energized.
Paper Feed Solenoid is energized.
Master Feed Clamper Solenoid is energized.
Master Eject Clamper Solenoid is energized.
Master Eject Solenoid is energized.
Paper Table Drive Motor rotates to move the paper table downward.
Paper Table Drive Motor rotates to move the paper table upward.
Relay for main motor reversing is energized.
Lamp is energized.
Cutter Motor rotates to move the cutter unit from the front of the machine to
rear.
Cutter Motor rotates to move the cutter unit from the rear of the machine to
front
Image Shifting Motor rotates in the (+) direction.
Image Shifting Motor rotates in the (–) direction.
Drum rotates at 10rpm.
Drum rotates at 20rpm.
Drum rotates at 60rpm.
Drum rotates at 75rpm.
Drum rotates at 90rpm.
Drum rotates at 105rpm.
Drum rotates at 120pm.
Original Transport Motor rotates.
Master Feed Motor rotates.
Thermal Head Energy is applied.
All the operation panel indicators are turned on.
Tape Maker (option) feeds out a strip of paper.
Printing operation is done at 10rpm.
Simulates original transportation in ADF mode.
NOTE:
1. If the drum is rotated using output check mode 26-0 to 32-0,
the drum rotation speed (rpm) is displayed in the copy counter.
2. After selecting output check mode 35-0 and pressing the Print
Start key, the thermal head voltage is continuously applied
until the Stop key or the Clear key is pressed. The beeper will
sound while the thermal head energy is applied.
WARNING:
Do not apply the thermal head voltage for more than several
seconds.
