No.
Item Remarks
15.
Pressure Plate
Motor
The master eject motor which had two functions: (one is to
drive the exit rollers, and the other to drive the pressure
plate) has been replaced by two motors; the master eject
motor and the pressure plate motor. Due to this
modification, the master box capacity has been increased.
16 Skip Feed
A user can select from 2 to 9 rotations of the drum
between each printed sheet of paper, as a result the
image will be darker than normal and more ink will be
consumed.
17.
Economy Function
(New Function)
If "Economy mode" is selected on the operation panel, a
lower thermal head energy is applied when a master is
made. As a result, the image will be lighter than normal
and ink consumption will be less.
18.
Security Mode
(New Function)
"Secret mode" can be selected by changing DIP
SW103-6. If this mode is selected, the Print key is
disabled after turning the main switch off and on. (Only the
"Master making key" is available for use.)
C224 1-6 SM
