Tech Service Bulletin No. VT2105 - 006
Page 3 of 4
••
UPDATE NO. 2 - PARTS STANDARDIZATION - Due to parts standardization, the following parts
have been changed.
REFERENCE
OLD PART NO. NEW PART NO. DESCRIPTION QTY INT PAGE ITEM
C2002005 C2222072 Bottom Stay 2 ➝ 2 0 11 11
C2033015 Bracket 1 ➝ 0 11 13
C2242015 Image Processing Board Bracket 0 ➝ 1 0 11 13
C2154505 C2194505 Drum Stopper Ass’y 1 ➝ 1 0 11 27
C2154506 C2194506 Stopper Base 1 ➝ 1 0 11 40
C2034512 C2244512 Grounding Spring Plate 1 ➝ 1 0 11 46
C2002340 Washer 1 ➝ 0 13 24
07010030Z Flat Washer - M3 0 ➝ 1 0 13 24
C2012226 C2192226 Gear - 22T 1 ➝ 1 0 13 33
14030539 Photointeruptor - EE-SX450-P1 n ➝ n-1 15
17
118
111
AW020041 Photointeruptor n ➝ n+1 0 15
17
118
111
55061535 Right Side Pad 2 ➝ 0 17 6
C2095092 Rubber Plate Lever 0 ➝ 2 0 17 6
C2035126 C2245126 Right Rack - Paper Feed 1 ➝ 1 0 17 25
C2035128 C2245128 Left Rack - Paper Feed 1 ➝ 1 0 17 40
C2005207 C2195127 Sector Gear Stud 1 ➝ 1 3/S 25 3
C2035175 C2245101 Sector Gear 1 ➝ 1 3/S 25 5
55015929 Spacer - 5.2 mm x 16 mm x 1 1 ➝ 0 3/S 25 1
56001086 Spacer - 10.2 x 20 1 ➝ 0 3/S 25 6
08077018 Washer - M10 1 ➝ 0 3/S 25 104
07200080Z Retaining Ring - M8 n ➝ n-1 3/S 25 106
C2136034 Gear 1 ➝ 0 33 9
C2196033 Gear - 50Z 0 ➝ 1 0 33 9
C2136009 C2246009 Driven Roller - Transport Belt 1 ➝ 1 0 37 11
55054189 C2156110 Felt - Side Plate 1 ➝ 1 0 39 22
Continued...
