System SP Tables-6
D017/D018/D019/D020/D084/D085 4-146 SM Appendix
6009
ADF Free Run
Performs an ARDF free run in duplex mode. Press [ON] to start, press [OFF]
to stop.
Note: This is a general free run controlled from the copier.
6010*
Stamp Position Adj.
Adjusts the stamp position in the sub-scan direction in fax mode.
[–5.0 to +5.0 / 0 / 1 mm/step]
6016*
Original Size Detection Priority
Specifies the original size for a size detected by the original sensor, since
original sensors cannot recognize all sizes.
(7) 0000 0000 (0)
Different bits are used for detection, depending on the location as shown
below.
Bit Size Location
7 A4 (L)/LT (L)
Japan only
6 11" x 15"/DLT (L)
5 DLT (L)/ 11" x 15"
NA only
4 LT (S)/ US Exec (S)
3 LT (L)/ 8" x 10" (L)
2 LG (L)/ F4 (L)
1 A4 (L)/ 16K (L)
EU/AA only
0 8K (L)/ DLT (L)
