System SP Tables-6
SM Appendix 4-147 D017/D018/D019/D020/D084/D085
Appendix:
Service
Program
Mode
6017
Sheet Through Magnification
Adjusts the magnification in the sub-scan direction for the ARDF.
[-5.0 to 5.0 / 0 / 0.1 %/step]
6117
Finisher Input Check
Displays the signals received from finisher sensors and switches. (See the
tables below.)
1 Group 1
2 Group 2
3 Group 3 (Only 1000 Fin)
4 Group 4 (Only 1000 Fin)
Check the status of each item against the 8-digit bit display listed in the table below.
Number Bit Description
Reading
0 1
Group 1
7
Stack Feed-out Belt HP
Sensor
Activated Deactivated
6 Not Used
5 Jogger Fence HP Sensor Activated Deactivated
4 Stapler HP Sensor Activated Deactivated
3 Stapler Tray Entrance Sensor Activated Deactivated
2 Not Used
1 Lower Tray Exit Sensor Activated Deactivated
0 Entrance Sensor Activated Deactivated
