System SP Tables-6
D017/D018/D019/D020/D084/D085 4-148 SM Appendix
Number Bit Description
Reading
0 1
Group 2
7 Not Used
6 Not Used
5 Stapler Ready Signal Activated Deactivated
4 Not Used
3 Not Used
2 Staple Sensor Activated Deactivated
1 Staple Hammer HP Sensor Activated Deactivated
0 Stapler Tray Paper Sensor Activated Deactivated
Number Bit Description
Reading
0 1
Group 3
7 Not Used
6
Lower Tray Lower Limit
Sensor
Activated Deactivated
5 Not used
4 Stack Height Sensor Activated Deactivated
3 Not Used
2 Not Used
1 Shift HP Sensor Activated Deactivated
0 Exit Guide HP Sensor Activated Deactivated
