Ricoh D017 - Page 582

System SP Tables-6
SM Appendix 4-149 D017/D018/D019/D020/D084/D085
Appendix:
Service
Program
Mode
Number Bit Description
Reading
0 1
Group 4
7 Not Used
6 Not Used
5 Not Used
4 Not Used
3
Upper Tray Paper Limit
Sensor
Activated Deactivated
2 Not Used
1 Not Used
0 Not Used
6118
Finisher Output Check
Switches on each electrical component of the finisher for testing.
Press [1] to switch on or [0] to switch off.
1 Upper Transport/Main Motor
2 Shift Tray Lift/Tray Motor
3 Staple Hammer Motor
4 Shift/Jogger Motor
5 Lower Transport Motor
6 Shift Tray Exit Motor
7 Tray Junction Gate Sol
8 Jogger Motor
