Shift Tray (D385)
D017/D018/D019/D020/D084/D085 2-37 SM
Installation
Set the shift tray on the stepped screw.
The shift tray must be installed under the paper guide [C] installed in step 3.
6. Connect the cable [D] to the copier.
7. Turn on the main power switch. Then select the shift tray with the user tool
System Settings - General Features - Output: Copier (and Output: Document
Server, Facsimile, Printer): Enable the shift tray – you can also enable the standard
tray (internal Tray 1), 1-bin tray (internal tray 2), or the finisher proof tray.
8. Check the shift tray operation.
