Duplex Unit (D369)
SM 2-44 D017/D018/D019/D020/D084/D085
This screw is removed in step 2.
Steps 13 and 14 described below are not required if the 1-Bin Tray has been
installed.
13. Install the duplex guide [A] ( x 1: M3x8).
14. Install the duplex tray guide [B] and duplex tray [C].
15. Turn on the main power switch and check the duplex unit function.
