4.Service Tables
96
3 Hang up setting at DIS reception disabled
0: No hang up
1: Hang up after transmitting DCN
Sets whether the machine disconnects after DIS
reception.
4 Number of times for training
0: 1 time, 1: 2 times
Selects the number of times training is done at the same
bit rate.
5 Space CSI transmission setting at no CSI
registration
0: Not transmitted
1: Transmitted
When "0" is selected, frame data is enabled.
When "1" is selected, the transmitted data is all spaces.
6-7 Not used Do not change these settings.
IP Fax Switch 08 (SP No. 1-111-009)
No. Function Comments
0-1 T1 timer adjustment Adjusts the T1 timer.
The default is "00" (35 seconds).
Bit 1 Bit 0
0 0 35 s
0 1 40 s
1 0 50 s
1 1 60 s
2-3 T4 timer adjustment Adjust the T4 timer.
The default is "00" (3 seconds).
Bit 3 Bit 2
0 0 3 s
0 1 3.5
s
1 0 4 s
1 1 5 s
4-5 T0 timer adjustment Adjusts the fail safe timer. This timer sets the interval between "setup" data
transmission and T.38 phase decision. If your destination return is late on the
network or G3 fax return is late, adjust the longer interval timer.
The default is "00" (75 seconds).
Bit 5 Bit 4
0 0 75 s
0 1 120
s
1 0 180
s
1 1 240
s
6-7 Not used Do not change these settings.
IP Fax Switch 09 (SP No. 1-111-010)
