4.Service Tables
97
No. Function Comments
0 Network I/F setting for SIP
connection
0: IPv4
1: IPv6.
Selects the connection type (IPV4 or IPV6) to connect to the SIP
server.
1 Network I/F setting for Fax
communication
0: Same setting as SIP server
connection
1: Automatic setting
0: The I/F setting for fax communication follows the setting for SIP
server connection.
1: The negotiation between the SIP server and the device decides
whether IPv4 or IPv6 is used for the I/F setting for fax
communication.
2 Record-route setting
0: Disable
1: Enable
0: Disables the record-route function of the SIP server.
1: Enables the record-route function of the SIP server.
3-4 re-INVITE transmission delay
timer setting
This changes the interval for transmit re-INVITE after receiving
the ACK message transmitted by T.38 device.
Bit 4 Bit 3
0 0 No delay
0 1 1 sec
1 0 2 sec
1 1 3 sec
5 SIP-IPFAX: Adding vender
information selection
0: Declare
T38VendorInfo=RICOH
1: Not declare
T38VendorInfo=RICOH
0: Use this setting normally.
1: This setting is used only when a customer wants to connect the
machine with SIP server + VOIP-GW provided by AVAYA Inc.
6-7 Not used. Do not change these settings.
IP Fax Switch 0A - Not used (do not change the settings)
IP Fax Switch 0B - Not used (do not change the settings)
IP Fax Switch 0C - Not used (do not change the settings)
IP Fax Switch 0D - Not used (do not change the settings)
IP Fax Switch 0E (SP No. 1-111-013)
No. Function Comments
0-1 SIP: IP-FAX port mode
(UDP)
00: 3 port mode
Switch the port mode for IP-FAX (T38 transport: UDP) at SIP call
control.
