4.Service Tables
115
1 0 1 1 26400
1 1 0 0 28800
1 1 0 1 31200
1 1 1 0 33600
1 1 1 1 Disabled
4-
7
Not used Do not change the settings.
Switch 03
No FUNCTION COMMENTS
0-
1
Inch-mm conversion
before tx
Bit 1: 0, Bit 0: 0
= Inch-mm conversion
available
Bit 1: 0, Bit 0: 1 = Inch
only
Bit 1: 1, Bit 0: 0 = Not
used
Bit 1: 1, Bit 0: 1 =
Disabled
If "inch only" is selected on the machine uses inch-based resolutions for
scanning, the printed copy may be slightly distorted at the other end if that
machine uses mm-based resolutions.
If the setting is "Inch-mm conversion available ", Inch-mm conversion become
effective to the special senders.
If the setting is "Disabled", the bit switch setting is used.
2-
3
DIS/NSF detection
method
Bit 3: 0, Bit 2: 0
= First DIS or NSF
Bit 3: 0, Bit 2: 1
= Second DIS or NSF
Bit 3: 1, Bit 2: 0 = Not
used
Bit 3: 1, Bit 2: 1 =
Disabled
(0, 1): Use this setting if echoes on the line are interfering with the set-up
protocol at the start of transmission. The machine will then wait for the second
DIS or NSF before sending DCS or NSS.
If the setting is "Disabled", the bit switch setting is used.
4 V.8 protocol
0: Off
1: Disabled
If transmissions to a specific destination always end at a lower modem rate
(14,400 bps or lower), disable V.8 protocol so as not to use V.34 protocol.
0: V.34 communication will not be possible.
If the setting is "Disabled", the bit switch setting is used.
5 Compression modes
available in transmit
This bit determines the capabilities that are informed to the other terminal
during transmission.
