SC2xx: Exposure
423
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
• Defective LD unit (Synchronizing mechanism or LDB failure)
• BiCU failure (Damaged laser ASIC)
• Disconnected LDB harness
1. Cycle the power off/on.
2. Check for condensation on the LDB.
3. Check the harness between LDB (Synchronizing mechanism) and BiCU.
4. Replace the LD unit.
5. Replace the BiCU.
6. Replace the harness between LDB and BiCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC230-01 D FGATE ON error: Bk
SC230-02 D FGATE ON error: Cy
SC230-03 D FGATE ON error: Ma
SC230-04 D FGATE ON error: Ye
FGATE signal cannot be received even when the laser is ready to emit.
This SC is detected when the machine is copying.
• Connection error between BiCU and Controller
• BiCU failure (Damaged laser ASIC)
1. Cycle the power off/on.
2. Check the connection between BiCU and Controller.
3. Replace the BiCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC231-01 D FGATE OFF error: Bk
SC231-02 D FGATE OFF error: Cy
SC231-03 D FGATE OFF error: Ma
SC231-04 D FGATE OFF error: Ye
FGATE signal is not OFF even when the laser is ready to end.
This SC is detected when the machine is copying.
• Connection error between BiCU and Controller
• BiCU failure (Damaged laser ASIC)
1. Cycle the power off/on.
2. Check the connection between IPU and Controller.
3. Replace the BiCU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
