Process Control Error Conditions
502
No. Result Description Possible Causes/Action
5. Check the connection.
6. Replace the BICU board.
3 ID sensor output
error
ID sensor output is more than "Voffset
Threshold" (SP3-324-004)
• Defective ID sensor
• Poor connection
• Defective BICU
1. Replace the ID sensor.
2. Check the connection.
3. Replace the BICU board.
9 Vsg Adjustment
error
Vsg adjustment has not been completed.
• Other cases
Retry SP3-321-010.
Line Position Adjustment Result
SP2-194-010 to -012 (Line Position Adjustment Result: M, C, Y)
This SP shows the number as a line position adjustment result on the LCD. It shows which color has an error
(M, Y or C).
No. Result Description Note
0 Not done Line position adjustment has not been done. -
1 Completed successfully Line position adjustment has correctly been done, -
2 Cannot detect patterns ID sensors have not detected the patterns for line position
adjustment.
See
Note
3 Fewer lines on the pattern
than the target
The patterns, which ID sensors have detected, are not enough for
line position adjustment.
See
Note
4 More lines on the pattern
than the target
Not used in this machine. -
5 Out of the adjustment
range
ID sensors have correctly detected the patterns for line position
adjustment, but a shift of patterns is out of adjustable range.
See
Note
6-9 Not used - -
• For details, see the "Troubleshooting Guide - Line Position Adjustment" section.
