Anti-condensation Heater (Mainframe)
83
4. Store the connector [A] in the connector holder, then push the power switch [B] into the switch hole until
you feel it click into place.
5. Cut out the switch hole [B] in the switch cover, and then attach the cover [A]. (Hooks × 2)
6. Route the junction harness as shown below.
To Next Page
