Ricoh Pro C9200 - 0703 [Half Fold Position: 1 Sheet Fold]

To Next Page

To Previous Page

Setting Items

Default

Value

Max.

Value

Min.

Value

Step Unit

[A3 SEF] 0.0 4.0 -4.0 0.2 mm

[B4 JIS SEF]

[A4 SEF]

[12 × 18 SEF]

[11 × 17 SEF]

× 14 SEF]

× 11 SEF]

[8K SEF]

[Other Paper Sizes]

0703 [Half Fold Position: 1 sheet Fold]

Adjust the edge of folding when Folding in Two is done by the Paper Folding Unit. It applies when Single

Folding is selected.

[Finishing: Fold]
