Ricoh Pro C9200 - 1102 [Auto Adjust Image Position]

Setting Item Max. Value Min. Value Step Unit
17: Operator Side/18: Opposite Side of
Operator
0.250 -0.250 0.001 %
[Switch Paper Edge Detection Sensor]
Select accuracy of paper edge detection sensor to correct image position in feeding direction. Select
[Normal] if paper jam(J031) occurs when the paper other than white is fed.
Setting Item Values
19: Setting [Normal]
[High Accuracy]
1102 [Auto Adjust Image Position]
[No. of Check Sheets]
Set the number of check sheets to be printed when Auto Adjust Image Position is executed.
Setting Item Max. Value Min. Value Step Unit
01: Front Side/02: Front & Back Sides 100 1 1 None
[Adjustment Mode]
Set the accuracy when Auto Adjust Image Position is executed.
4. Details of Menu Items in Advanced Settings
136
