Ricoh Pro C9200 - 0608 [Punch Position: with Feed]; 0609 [Punch Skew Correction]

Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[2 Holes JP/ EU] 0.0 2.0 -2.0 0.5 mm
[3 Holes US]
[4 Holes EU]
[4 Holes NE]
[2 Holes US]
0608 [Punch Position: With Feed]
Adjust the position (left and right) of the punch holes in the feeding direction. Use [+] to move away from
the back end, and [-] to move toward the back end.
Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
[2 Holes JP/ EU] 0.0 4.0 -4.0 0.5 mm
[3 Holes US]
[4 Holes EU]
[4 Holes NE]
[2 Holes US]
0609 [Punch Skew Correction]
Set whether or not to correct the punch skew. If jam or ear-fold occurs at the punch section especially
when thin paper is used, set it to [Off].
2. Details of Menu Items in Adjustment Settings for Operators
58
