0602 [Staple Position: Across Feed 2]

Adjust the space of the two staples in the vertical direction. Use [+] or [-] to expand or shrink the space.

Setting Items

Default

Value

Max.

Value

Min.

Value

Step Unit

[A3 SEF] 0 115 -16 1 mm

[B4 JIS SEF] 75

[A4 LEF] 115

[A4 SEF] 28

[B5 JIS LEF] 75

[B5 JIS SEF] 0

[11 × 17 SEF] 98

× 14 SEF] 34

× 11 LEF] 98

× 11 SEF] 34

[8K SEF] 85

[16K LEF] 85

[16K SEF] 12

[Other Paper Sizes] 115

0603 [Staple Position: With Feed]

Adjust the position of the staple in the horizontal direction. Use [+] or [-] to expand or reduce the

distance to the back end of paper.

[Finishing: Finisher]

Table of Contents3
Introduction10
How to Read this Manual11
- Symbols11
- Disclaimer11
- Notes11
Manuals for this Machine12
Paper Feed Direction of Printed Copies (Side 1/Side 2)13
Adjustment Settings for Operators15
Accessing Adjustment Settings for Operators15
Layout of Adjustment Settings for Operators16
Features of the Displayed Items and Setting Operations17
Notes on How Adjustment Settings Are Applied to Printed Copies20
Details of Menu Items in Adjustment Settings for Operators25
[Machine: Image Position]25
- 0101 [Image Position: with Feed: Side 1]/0102 [Image Position: with Feed: Side 2]25
- 0103 [Image Position: Across Feed: Side 1]/0104 [Image Position: Across Feed: Side 2]26
- 0107 [Image Magnification: Across Feed: Side 1]/0108 [Image Magnification: Across Feed: Side 2]28
- 0109 [Perpendicularity Adjustment]29
- 0110 [Switch Paper Edge Detection Sensor]29
- 0111 [Auto Adjust Image Position: No. of Printed Sheets]30
- 0112 [Auto Adjust Image Positn: Magn Adjust Range: with Feed]30
[Machine: Image Quality]32
- 0201 [Execute Image Quality Adjustment]32
- 0202 [Maximum Image Density]32
- 0203 [Line Width]32
- 0204 [Fusing Temperature on Standby]33
[Machine: Paper Feed/ Output]34
- 0301 [Correct Output Paper Curl: 1 Sided: Face Up]/0302 [Correct Output Paper Curl: 1 Sided: Face Down]/0303 [Correct Output Paper Curl: 2 Sided]34
- 0304 [Detect JAM099]34
- 0305 [Detect JAM080]35
- 0306 [Detect J097/098]36
- 0307 [Control J097/098]36
- 0308 [Detect JAM048]37
[Machine: Productivity]38
- 0401 [No. of Sheets for Auto Color Selection]38
- 0402 [Print Mode When Switching Paper Type]38
- 0403 [Paper Feed Interrupt Setting]38
[Machine: Maintenance]40
- 0501 [Execute Cleaning Initial Setting for PCU]40
- 0502 [Wind Fuser Cleaning Unit at Replacement]40
- 0503 [Reset Parts Counter]40
- 0504 [Display Parts Life Counter]42
- 0505 [Temperature / Humidity Inside]44
- 0506 [Temperature / Humidity Outside]45
- 0507 [Screw-On Cap to Replace]45
- 0508 [Execute Developer Refreshing]45
- 0509 [Execute Photoconductor Refreshing]46
- 0510 [Execute Charger Unit Cleaning]46
- 0511 [Execute Cleaning Initial Setting: Ppr Trns Unit]46
- 0512 [Fusing Belt Smoothing Setting]47
- 0513 [Smooth Fusing Belt]47
- 0514 [Fusing Belt Smoothing Execution Time]47
- 0515 [Fusing Belt Smoothing Setting (Set by User)]48
- 0516 [Manage Multiple Fusing Units by Counter]48
[Finishing: Finisher]54
- 0601 [Staple Position: Across Feed 1]54
- 0602 [Staple Position: Across Feed 2]55
- 0603 [Staple Position: with Feed]55
- 0604 [Paper Alignment for Stapling: Across Feed]56
- 0605 [Paper Alignment for Stapling: with Feed]57
- 0606 [Number of Sheets Align for Stapling]58
- 0607 [Punch Position: Across Feed]59
- 0608 [Punch Position: with Feed]60
- 0609 [Punch Skew Correction]60
- 0610 [Amount of Punch Skew Correction]61
- 0611 [Paper Alignment in Shift Tray Setting]61
- 0612 [Paper Alignment in Shift Tray: Across Feed]62
- 0613 [Output Tray Descending Position]62
- 0614 [Exit Guide Close Timing]63
- 0615 [Output Trail Edge Press Setting]63
- 0616 [Output Fan Setting]63
- 0617 [Output Fan Level]64
- 0618 [Staple Position for Booklet]64
- 0619 [Folding Position for Booklet]65
- 0620 [Paper Alignment for Booklet: Across Feed]66
- 0621 [Set Number of Folds for Booklet]67
- 0622 [Paper Alignment for Booklet: with Feed]68
- 0623 [Z-Fold Skew Correction]69
- 0624 [Amount of Z-Fold Skew Correction]69
- 0625 [Amount of Z-Fold Skew Correction: Reverse]69
- 0626 [Maximum No. Stacked Sheets in Output Tray]70
- 0630 [Staple Position for Booklet]70
- 0631 [Folding Position for Booklet]71
- 0632 [Staple Position: Across Feed 1]73
- 0633 [Staple Position: Across Feed 2]73
- 0634 [Staple Position: with Feed]74
- 0635 [Punch Position: Across Feed]75
- 0636 [Punch Position: with Feed]76
- 0637 [Paper Alignment for Booklet: Across Feed]77
- 0638 [Set Number of Folds for Booklet]78
- 0639 [Feed Amount of Folding Roller for Booklet]79
- 0640 [Paper Alignment for Booklet: with Feed]79
- 0641 [Paper Alignment for Stapling: Across Feed: 1St Time]81
- 0642 [Paper Alignment for Stapling: Across Feed: 2Nd Time]81
- 0643 [Paper Alignment for Stapling:paper Weight:across Feed:1St]82
- 0644 [Paper Alignment for Stapling:paper Weight:across Feed:2Nd]83
- 0645 [Paper Alignment in Shift Tray: Across Feed]84
- 0646 [Paper Alignment for Stapling: with Feed: 1St Time]85
- 0647 [Paper Alignment for Stapling: with Feed: 2Nd Time]86
- 0648 [Paper Alignment for Stapling:paper Weight:with Feed:1St]87
- 0649 [Paper Alignment for Stapling:paper Weight:with Feed:2Nd]88
- 0650 [Punch Skew Correction]89
- 0651 [Z-Fold Skew Correction]89
- 0652 [Amount of Z-Fold Skew Correction]90
- 0653 [Amount of Z-Fold Skew Correction: Reverse]90
- 0654 [Amount of Punch Skew Correction]91
- 0655 [Paper Alignment in Shift Tray Setting]91
- 0656 [Paper Alignment in Shift Tray Setting: Stapled Signature]92
- 0657 [Paper Alignment in Shift Tray Setting: Thin Paper]92
- 0658 [Number of Sheets Align for Stapling]92
- 0659 [Output Tray Descending Position]93
- 0660 [Output Trail Edge Press Setting]94
- 0661 [Output Fan Setting]94
- 0662 [Output Fan Level]94
- 0663 [Maximum No. Stacked Sheets in Output Tray]94
- 0664 [Max. No. Stacked Sheets in Output Tray: Stapled Signature]95
- 0665 [Maximum No. Stacked Sheets in Output Tray: Envelope]95
- 0666 [Staple Tray: Rib Installed Mode to Strengthen Paper]96
- 0667 [Accuracy Priority for Stapling]96
- 0668 [Accuracy Priority for Booklet]96
- 0669 [Convert Number of Sheets for Booklet]97
- 0670 [Paper Alignment Gap for Stapling]97
- 0671 [Paper Alignment Angle on Shift Tray]98
- 0672 [Prevent Misdetection of Punched Hole]98
[Finishing: Fold]100
- 0701 [Z-Fold Position 1]100
- 0702 [Z-Fold Position 2]100
- 0703 [Half Fold Position: 1 Sheet Fold]101
- 0704 [Half Fold Position: Multi-Sheet Fold]102
- 0705 [Letter Fold-Out Position 1: 1 Sheet Fold]104
- 0706 [Letter Fold-Out Position 1: Multi-Sheet Fold]104
- 0707 [Letter Fold-Out Position 2: 1 Sheet Fold]105
- 0708 [Letter Fold-Out Position 2: Multi-Sheet Fold]106
- 0709 [Letter Fold-In Position 1: 1 Sheet Fold]106
- 0710 [Letter Fold-In Position 1: Multi-Sheet Fold]107
- 0711 [Letter Fold-In Position 2: 1 Sheet Fold]108
- 0712 [Letter Fold-In Position 2: Multi-Sheet Fold]109
- 0713 [Double Parallel Fold Position 1]/0714 [Double Parallel Fold Position 2]110
- 0715 [Gate Fold Position 1]111
- 0716 [Gate Fold Position 2]112
- 0717 [Gate Fold Position 3]113
- 0718 [Folding Unit Tray Full Detection]114
- 0719 [Number of Sheets Folded after Full Detection]114
[Finishing: Perfect Binder]116
- 0801 [Perf Bind Cvr Sht Posit: Across Feed]116
- 0802 [Perf Bind Cvr Sht Posit: with Feed]116
- 0803 [Perfect Binding Finishing Angle]116
- 0804 [Applying Binding Glue]117
[Finishing: Stacker]118
- 0901 [Ppr Align in Stack Tray: Acr Feed 1]118
- 0902 [Ppr Align in Stack Tray: Acr Feed 2]119
- 0903 [Paper Alignment in Stacker Tray: with Feed]119
- 0904 [Ppr Align in 2Nd Stack Tray: Acr Feed 1]120
- 0905 [Ppr Align in 2Nd Stack Tray: Acr Feed 2]121
- 0906 [Ppr Align in 2Nd Stack Tray: with Feed]122
- 0907 [Maximum Stack Quantity in Stacker Tray]123
[Density Difference Printing: Across Feed]125
[Finishing: Interposer]126
- 2101 [Detect JAM573]126
- 2101 [Detect JAM574]126
- 2102 [Interposer Fan Setting]126
- 2103 [Interposer Fan Level]127
Custom Paper Settings for Administrators129
Accessing Advanced Settings129
Description of Paper Icons130
Deleting Saved Custom Paper Profiles131
Backing up and Restoring Custom Paper Profiles132
- Backing up Custom Paper Profiles Registered under the [Custompaper Management] Setting132
- Backing up and Restoring Custom Paper Profiles Using the External Controller's Control Panel133
Paper Presets in "Advanced Settings134
- Displaying the Paper Profile Version134
Details of Menu Items in Advanced Settings135
[Machine: Image Position]135
- 1101 [Image Position]135
- 1102 [Auto Adjust Image Position]138
- 1103 [Image Position Feedback Correction]139
- 1104 [Image Position Gap]139
[Machine: Image Quality]141
- 1201 [Max Image Density]141
- 1212 [Image Transfer Output]141
- 1214 [Paper Transfer Output]141
- 1215 [Image Transfer Output Correction]142
- 1217 [Paper Transfer Output Correction: Paper Edge]143
- 1229 [Paper Transfer Pressure]144
- 1230 [Paper Transfer Roller Reverse Rotation]144
- 1241 [Fusing Temperature]145
- 1242 [Fusing Pressure Roller on before Fusing]146
- 1243 [Fusing Pressure Roller on after Fusing]146
- 1244 [Fusing Cleaning]147
- 1245 [Margin]147
- 1246 [Fusing Nip Width Adjustment]147
- 1247 [Fusing Temperature Range]148
- 1248 [Fusing Pressure Roller Cooling]148
- 1249 [Fusing Belt Smoothing]148
- 1250 [Print Mode When Switching Paper Type]149
[Machine: Paper Feed/ Output]150
- 1301 [Main/2-Tray LCIT: Paper Feed Mode]150
- 1302 [Main/2-Tray LCIT: Fan/Shutter]150
- 1303 [Main/2-Tray LCIT: Other Setting]153
- 1311 [Correct Paper Curl]153
- 1321 [Jam Detection]154
- 1331 [Motor Speed]155
- 1341 [Adjust Paper Curl (Fusing)]156
