Ricoh SP 330DN Service Manual

Smart Organizing Monitor (SOM)
SM 5-47 M0C3/M0C4/M0C5/M0C6/M0C7
System
Maintenance
Group Item Remarks
Vertical: Thin
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Registration:
Bypass Tray
Horizontal [-40 to 40 / -5* / 0.1 mm/step]
Vertical: Plain
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Vertical: Thick
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Vertical: Thin
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Registration:
Duplex Tray
Horizontal [-40 to 40 / 8* / 0.1 mm/step]
Vertical: Plain
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Vertical: Thick
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Vertical: Thin
Paper
[-40 to 40 / 23* / 0.1 mm/step]
Output check Main Motor Output check (Main motor)
Middle Clutch Output check (Relay clutch)
Tray1 Clutch Output check (Paper feed clutch)
Bypass
solenoid
Output check (Bypass solenoid)
Registration
clutch
Output check (Registration clutch)
Fan High
Speed
Output check (Fan high speed)
Fan Low Speed Output check (Fan low speed)
Erase Lamp Output check (Quenching lamp)
Polygon Motor Output check (Polygon motor)
Duplex Motor
Normal
Output check (Duplex motor normal)
Duplex Motor
Reverse
Output check (Duplex motor reverse)
Print Cartridge Information Displays Print Cartridge Information.
Displays:
Print cartridge: Kind ID, Toner End History, Refill Flag
Status, Unit Print Counter
OPC: OPC Rotation Time, Prev. OPC rotation time, Alert

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
