Sensors
M534 10 SM
1.7 SENSORS
1.7.1 PAPER FEED SENSOR
1. Remove the right cover (Right Cover).
2. Release the actuator [A] from the slot of the paper feed sensor [B].
3. Remove the paper feed sensor [B] (all hooks,
x1).
1.7.2 PAPER END SENSOR
1. Remove the right cover (Right Cover).
2. Release the actuator [A] from the slot of the paper exit sensor [B].
3. Remove the paper end sensor [B] (all hooks,
x1).
