Ricoh SP 330DN Service Manual

Maintenance Mode (for Touch Panel Models)
M0C3/M0C4/M0C5/M0C6/M0C7 5-22 SM
Fax Service Setting
Menu Description
Modem
Settings
RX Level
Sets the reception level.
[-43 dBm (Default)/ -33 dBm/ -26 dBm/ -16 dBm]
TX Level
Sets the transmission level.
[-15 to -1 / -9(Default)/ 1dBm/ step]
Cable Equalizer
These selectors are used to improve the pass-band
characteristics of analogue signals on the telephone line.
[0Km (Default)/ 1.8Km/ 3.6Km/ 7.2Km]
Protocol
Definition
Training Retries
This sets the number of training retries to be repeated before
automatic fallback.
[1 Time/ 2 Times (Default)/ 3 Times/ 4 Times]
Encoding
Sets the compression method for Tx/Rx.
[MMR+MR+MH (Default)/ MR+MH/ MH]
Protocol
Definition
Timer
T0 Timer
Timeout for response from the called station in automatic
sending mode
[35 Sec/ 45 Sec/ 55 Sec (Default)/ 60 Sec/ 90 Sec/ 140 Sec]
T1 Timer
Set the time length for the T1 timer.
[40 Sec (Default)/ 50 Sec]
T4 Timer
Set the time length for the T4 timer.
[3 Sec (Default/ 4.5 Sec]
RX Settings CNG Tone
Detection
CNG tone detection time (RX mode : FAX / TEL, FAX / TAD
Only)
After the line is connected via the external telephone, the
machine can detect a CNG signal for the time length specified
by this setting.
[5 Sec (Default)/ 10 Sec]
CNG Cycles
Number of CNG cycles to be detected
This setting is only effective for FAX/TAD mode.
[1.5 Cycle (Default)/ 2.0 Cycle]
Tone Sound
Monitoring
Determines the period when tones from the line are
monitored.

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
