Ricoh SP 330DN - Left Cover

Exterior Covers (MF Models)
SM 4-13 M0C3/M0C4/M0C5/M0C6/M0C7
Replacement
and
Adjustment
4.3.2 LEFT COVER
1. Remove the front cover (Front Cover).
2. Remove the two screws on the front side of the left cover [A].
3. Pull the front upper part of the left cover [A] to release the hook.
• The outside of the cover has marks indicating the position of the hooks.
4. Pull the front bottom part of the left cover [A] to release the hook.
