Fax Service Test (Only for Fax Models)
SM 5-53 M0C3/M0C4/M0C5/M0C6/M0C7
Maintenance
5.4 FAX SERVICE TEST (ONLY FOR FAX MODELS)
5.4.1 FAX SERVICE TEST MENU
Entering the Fax Service Test Menu
Turn on the machine while pressing the [Home] key, and hold on pressing it until displayed "Fax
Service Test".
Selecting an Item
Select the item which you want to execute.
Exiting the Fax Service Test Menu
Press [Exit].
5.4.2 MENU LIST
Menu
Description
Off-Hook Test On Hook Executes the on hook test.
Off Hook Executes the off hook test
CED Test Executes the CED test.
CNG Test 1100 Hz Executes the CNG test
ANSam Test Executes the ANSam test.
Ring Tone Test Executes the ring tone test.
DTMF Test Tone [0] to [9] Executes the DTMF tone 0 to 9 test.
Tone [*] Executes the DTMF tone * test.
Tone [#] Executes the DTMF tone # test.
Tone Stop Executes the Stop DTMF tone test.
Modem Test [V34] 33600 Bps Generates the [V34] 33600 bps signal.
[V34] 28800 Bps Generates the [V34] 28800 bps signal.
[V17] 14400 Bps Generates the [V17] 14400 bps signal.
[V17] 12000 Bps Generates the [V17] 12000 bps signal.
[V17] 9600 Bps Generates the [V17] 9600 bps signal.
To Next Page
