Ricoh SP 330DN Service Manual

Machine Codes and Peripherals Configuration
SM 1-1 M0C3/M0C4/M0C5/M0C6/M0C7
Product
Information
1. PRODUCT INFORMATION
1.1 MACHINE CODES AND PERIPHERALS
CONFIGURATION
1.1.1 MAIN FRAME
Printer Models:
Name Machine Code Operation Panel Remarks
SP 330DN M0C3 Four-line LCD For NA/EU/AA/CHN/TWN
SP 3710DN M0C6 Four-line LCD For NA/EU/AA
MF Models:
Name Machine
Code
Operation
Panel
ADF Fax Remarks
SP 330SN M0C4 Four-line LCD ADF Not
supported
For EU/AA/CHN
SP
330SFN
M0C5 4.3" touch
panel
ARDF Supported For
NA/EU/AA/CHN/TWN
SP
3710SF
M0C7 4.3" touch
panel
ARDF Supported For NA/EU/AA
NA = North America, EU = Europe, AA = Asia-Pacific, CHN = China, TWN = Taiwan
1.1.2 OPTIONS
Name Machine Code Remarks
Paper Feed Unit PB1130 M534-17
New
Paper Capacity: 250 sheets
IEEE 802.11 Interface Unit Type P16 M542-01
New
USB dongle type

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
