Ricoh SP 330DN Service Manual

Maintenance Mode (for Touch Panel Models)
SM 5-23 M0C3/M0C4/M0C5/M0C6/M0C7
System
Maintenance
Menu Description
[No Monitoring/ Up To Phase B (Default)/ All TX Phases]
Stop/Clear Key
Pressing the Stop/Clear key can stop the current receiving
operation. Received data is lost.
[No Functional (Default)/ Functional]
Off-Hook
Detection
Sets the Off-Hook detection period.
[200 msec (Default)/ 800 msec]
Number for
Remote Switch
[0～9 / 2 (Default/ 1digit/step]
Number of time
to press
[1～3 / 2 (Default/ 1time/step]
Period: TEL to
Fax
[Limitless / 10 sec (Default/ 20 sec / 30 sec / 40 sec]
TX Settings Redial Interval
Sets the redial interval when Tx fails.
[5 Min (Default)/ 6 Min]
Redialings
Sets the number of redials when Tx fails.
[2 times (Default)/ 3 Times/ 4 Times/ 5 Times]
Overseas
Comm Mode
Settings
Overseas
Comm Mode
This sets the machine to ignore a DIS signal sent from the
called station once in a sending operation.
[Off (Default)/ Ignore DIS Once]
Minimum Time
Length
If this setting is set to "On", the machine detects the CNG
signal after the line is connected. If it is set to "Off", the
machine detects the CNG signal as long as the line is
connected.
[100 Ms/ 200 Ms/ 300 Ms/ 400 Ms (Default)]
Dial Pulse
Setting
Dial Pulse Type
This sets the number of pulses that are generated during
dialing.
• N: Dialing '0' generates 10 pulses --- Dialing '9' generates
9 pulses. (Default)
• N+1: Dialing '0' generates 1 pulses --- Dialing '9' generates
10 pulses.
• 10-N: Dialing '0' generates 10 pulses --- Dialing '9'
generates 1 pulse.
Tone Signal Tone Signal
Sets the tone signal transmission time length

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
