Ricoh SP 330DN Service Manual

Maintenance Mode (for Touch Panel Models)
M0C3/M0C4/M0C5/M0C6/M0C7 5-24 SM
Menu Description
Settings Transmission T [100 ms (Default)]
Minimum Pause
In Tone Dial
Sets the minimum pause during tone dialing
[100 ms (Default)/ 150 ms/ 200 ms]
Attenuator of
Pseudo Ring
Sets the attenuator for pseudo ringback tone to the line
[0 to 15 / 10 (Default)/ 1 dB/step]
DTMF Level
Sets the transmission level of DTMF tones.
[-12 dBu / -11 dBu/ -10 dBu (Default)/ -8 dBu/ -6 dBu]
DTMF Delta
Sets the level difference between high band frequency
signals and low band frequency signals when sending DTMF
tones.
[1 dBu/ 2 dBu (Default)/ 3 dBu]
1Dial Tone
Detection
Wait Time
The machine starts dialing after the specified interval without
detection of a dial tone when dial tone detection is set to "No
detection".
[3.5 Sec (Default)/ 7.0 Sec/ 10.5 Sec/ 14.0 Sec]
Timeout Length
This setting sets the time-out length for the 1st dial tone
detection. The machine waits for a dial tone for the specified
time and disconnects itself from the line when no dial tone is
input.
[10 Sec (Default)/ 15 Sec/ 20 Sec/ 30 Sec]
BT (Busy
Tone)
Detection
BT Setting
DFU
[Off/ On(Default)]
BT Frequency
DFU
[300-550 Hz/ 300-650 Hz/ 325-525 Hz/ 340-550 Hz/ 350-500
Hz (Default)/ 350-550 Hz/ 375-475 Hz/ 380-520 Hz]
BT Level
DFU
[-35 dB/ -36 dB/ -37 dB/ -38 dB/ -39 dB (Default)]
BT Cadence
DFU
[0.10/ 0.15/ 0.20/ 0.25/ 0.30/ 0.35/ 0.40/ 0.45/ 0.50 (Default)/
0.75]
Comm RTN Rate
The machine checks the actual data reconstruction errors

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
